This site also includes a more detailed technical page about Shimano Cassettes.
It is generally good practice to replace your chain when you install a new cassette. We recommend SRAM (Formerly Sachs (Formerly Sedis)) chains, and offer then at excellent prices to our Web customers. Click here for details.
| Standard Shimano 7-speed Cassettes: | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Series | Price | Code | Sprockets | Weight | ||||||
| CS704 | HG-70C | Limited supply! $39.95 | ac | 11 | 13 | 15 | 18 | 21 | 24 | 28 | 303 grams |
| CS728 | HG-50 Black | $29.95 | L | 12 | 13 | 14 | 15 | 17 | 19 | 21 | 220 grams |
| CS730 | HG-50 Black | $29.95 | E | 12 | 14 | 16 | 18 | 21 | 24 | 28 | 301 grams |
| CS732 | HG-50 Black | $29.95 | I | 13 | 14 | 15 | 17 | 19 | 21 | 23 | 262 grams |
| CS733 | HG-50 Black | $29.95 | H | 13 | 15 | 17 | 19 | 21 | 23 | 26 | 311 grams |
| CS735 | HG-50 Black | $29.95 | M | 13 | 15 | 17 | 19 | 21 | 24 | 28 | 328 grams |
| CS737 | HG-50 Black | $29.95 | G | 13 | 15 | 17 | 20 | 23 | 26 | 30 | 328 grams |
| CS738 | HG-50 Black | $29.95 | K | 13 | 15 | 17 | 20 | 24 | 29 | 34 | 405 grams |
| CS739 | HG-50 Black | $29.95 | F | 14 | 16 | 18 | 21 | 24 | 28 | 32 | 360 grams |
4.5 mm spacer to fit a 7-speed cassette onto a hub made for 8-, 9-, or 10-speed cassettes. CS004 $5.95
![]()
Shimano 9 Speed Cassette Spacers (for in between sprockets) 2.56mm CS009 $3.95
If your cassette has bolts holding the sprockets together, you will need to remove the bolts. They are not necesssary, only intended as a convenience for rapid cassette swaps.
Convert a 7- or 8-/9-speed Shimano Freehub to singlespeed
| Harris Cyclery Exclusive Custom 8-speed Touring Cassettes by Sheldon Brown: | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CS835 | $59.95 | 13 | 15 | 17 | 19 | 21 | 23 | 26 | 30 | ||||
| CS836 | $59.95 | 13 | 15 | 17 | 19 | 21 | 23 | 26 | 32 | ||||
| CS837 | $59.95 | 13 | 15 | 17 | 19 | 21 | 23 | 26 | 34 | ||||
| Standard Shimano 8-speed Cassettes: | |||||||||||||
| Part Number | Series | Price | Sprockets | ||||||||||
| CS819 | HG-50 New! | $29.95 | 11 | 13 | 15 | 17 | 19 | 21 | 24 | 28 | |||
| CS823 | HG-50 | $29.95 | 11 | 13 | 15 | 17 | 20 | 23 | 26 | 30 | |||
| CS825 | HG-50 | $29.95 | 11 | 13 | 15 | 18 | 21 | 24 | 28 | 32 | |||
| CS832 | HG-50 | 29.95 | 13 | 14 | 15 | 17 | 19 | 21 | 23 | 26 | |||
| Harris Cyclery Exclusive Custom 9-speed Cassettes by Sheldon Brown: | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
These cassettes are made entirely from genuine Shimano parts, rearranged to offer gearing options not otherwise available. | ||||||||||||||
| CS915 Big Dozen SLX | $69.95 | 12 | 13 | 14 | 16 | 18 | 21 | 24 | 28 | 32 |
| |||
| CS916 Big Dozen XT | $119.95 | 12 | 13 | 14 | 16 | 18 | 21 | 24 | 28 | 32 |
| |||
The "Big Dozen" is a good all-around cassette for wide-range systems with 46-48 tooth large chainrings. XT version has larger sprockets mounted on a Spider to save weight, SLX uses discrete sprockets. | ||||||||||||||
| High & Wide | See the new Shimano HG-80 11-28t below | 11 | 12 | 13 | 14 | 16 | 18 | 21 | 24 | 28 | ||||
The "High and Wide" is a good choice for bikes with small rear wheels. | ||||||||||||||
| CS922 Century Special | 119.95 | 13 | 14 | 15 | 17 | 19 | 21 | 24 | 27 | 30 | ![]() 310 grams | |||
The "Century Special" is our most popular custom cassette. It works with all modern derailers, even short cage models. | ||||||||||||||
| CS914 Century 12 | 105.95 | 12 | 13 | 15 | 17 | 19 | 21 | 24 | 27 | 30 | ![]() 310 grams | |||
By popular demand, 12-30 range. You give up the 14 of the Century Special for the 12. | ||||||||||||||
| CS923 Cyclotouriste 13 | $124.95 | 13 | 15 | 17 | 19 | 21 | 24 | 27 | 30 | 34 |
| |||
| CS925 Cyclotouriste 14 | $124.95 | 14 | 15 | 17 | 19 | 21 | 24 | 27 | 30 | 34 |
| |||
Our "Cyclotouriste" cassettes are an excellent choice for loaded touring bikes with full-sized chainrings, giving excellent climbing gears without sacrificing comfortable gear spacing for useless high end gears. | ||||||||||||||
Standard 9 Speed Shimano Cassettes
| Part | Number Series | Price | Sprockets | Weight
| CS901 | Ultegra 9 | $95.95 | 11 | 12 | 13 | 14 | 15 | 17 | 19 | 21 | 23 | 190 grams
| CS907 | Ultegra 9 | $95.95 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 21 | 196 grams
| CS909 | Ultegra 9 | $95.95 | 12 | 13 | 14 | 15 | 16 | 17 | 19 | 21 | 23 | 202 grams
| CS911 | Ultegra 9 | $95.95 | 12 | 13 | 14 | 15 | 17 | 19 | 21 | 23 | 25 | 217 grams
|
CS913 | Ultegra 9 | $95.95 | 12 | 13 | 14 | 15 | 17 | 19 | 21 | 24 | 27 | 224 grams
| CS921 | Ultegra 9 | $95.95 | 13 | 14 | 15 | 16 | 17 | 19 | 21 | 23 | 25 | 238 grams
| CS924 | Ultegra 9 | $95.95 | 14 | 15 | 16 | 17 | 18 | 19 | 21 | 23 | 25 | 254 grams
| New! | CS902 HG-80 | $84.95 | 11 | 12 | 13 | 14 | 16 | 18 | 21 | 24 | 28 | 230 grams
| CS903 | HG-61 SLX | $54.95 | 11 | 12 | 14 | 16 | 18 | 21 | 24 | 28 | 32 | 287 grams
| CS906 | HG-61 SLX | $54.95 | 11 | 13 | 15 | 17 | 20 | 23 | 26 | 30 | 34 | 290 grams
| New! | CS916A HG-61 SLX | 12-36t $59.95 | 12 | 14 | 16 | 18 | 21 | 24 | 28 | 32 | 36 | Designed for 29ers. | Makes a great touring cassette! CS904 | M770 XT | $99.95 | 11 | 12 | 14 | 16 | 18 | 21 | 24 | 28 | 32 | 260 grams
| CS905 | M770 XT | $99.95 | 11 | 13 | 15 | 17 | 20 | 23 | 26 | 30 | 34 | 264 grams
| | ||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
The Capreo hub/cassette is designed for bicycles with small drive wheels, typically folding bikes and recumbents.The Capreo cassette is the only cassette that features sprockets smaller than 11 teeth. The sizes are:
| 9 | 10 | 11 | 13 | 15 | 17 | 20 | 23 | 26 |
|---|
Note: Capreo cassettes are not interchangeable with other Shimano cassettes. They only fit Capreo Freehubs , and Capreo Freehubs only work with Capreo cassettes.
The 2004 Dura-Ace hub has an aluminum Freehub body, so it only works with 10 speed cassettes.
This is not true of the Ultegra 10 hub.
The Ultegra 10 will take any standard Shimano cassette.
Dura-Ace 10 cassettes have titanium sprockets from 18 teeth and larger.
10-speed cassettes have a recess built into the back of the big spider module, allowing them to fit farther onto the Freehub body than older cassettes. This limits the possiblities of customizing the ratios, because you can't install a flat sprocket behind the spider module...you run out of clearance at the other end if you try.
| IRD (Interlock Racing Designs 10-speed Cassettes (for Shimano systems.) 4 largest sprockets are paired on aluminum "spider" modules. These wide-range touring cassettes require a long-cage (SGS) rear derailer, such as Deore, LX, XT, XTR They don't shift as smoothly as Shimano (what does?) but they do work, and will get you up some hills that a smaller cassette won't. | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Series | Price | Sprockets | Weight | ||||||||||
| CSX830 | Elite 10 | $159.95 | 11 | 13 | 15 | 17 | 19 | 21 | 23 | 25 | 28 | 32 | 351g | |
| CSX831 | Elite 10 | $159.95 | 11 | 13 | 15 | 17 | 19 | 21 | 23 | 25 | 28 | 34 | 360g | |
Standard Shimano Cassettes
| Part | Number Series | Price | (Click 'Cart' button) Sprockets | Weight
| CSX02 | Ultegra 10 | | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 21 | 23 |
| CSX04 | Ultegra 10 | | 12 | 13 | 14 | 15 | 16 | 17 | 19 | 21 | 23 | 25 |
| CSX06 | Ultegra 10 | 12 | 13 | 14 | 15 | 16 | 17 | 19 | 21 | 24 | 27 |
| New! | CSX613 Ultegra 10 | 6700 Series | 11 | 12 | 13 | 14 | 15 | 17 | 19 | 21 | 24 | 28 | 238g
| | |||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| The Ultimate 10-Speed Touring Cassette!
Designed for Shimano's Shadow technology Mtn Bike components, This cassette can be used on a touring bike | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Series | Price | Sprockets | Weight | |||||||||||
| New! CSX145 | SLX HG81 | $89.95 | 11 | 13 | 15 | 17 | 19 | 21 | 24 | 28 | 32 | 36 | 364g | ||
| SRAM 10-speed Cassettes (for Shimano systems) Forged alloy spider holds largest cogs These wide-range touring cassettes require a long-cage (SGS) rear derailer, such as Deore, LX, XT, XTR Affordable 10 speed cassette in 11-32 size! | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Series | Price | Sprockets | Weight | ||||||||||
| New! CSX228 | PG-1050 | $82.95 | 11 | 12 | 14 | 16 | 18 | 20 | 22 | 25 | 28 | 32 | 299g | |
Cassettes that feature an 11 tooth sprocket are intended to fit "C" (Compact) hub bodies only. The spline grooves in the 11 do not run all the way through (it wouldn't be strong enough if they did.)These cassettes can be fitted onto older bodies two ways:
- If you install a 1 mm spacer before the cassette, the cassette will fit, but the cassette will then be 1 mm farther to the right than it is intended to be. With most bikes, this won't be a problem, but if your frame has very tight clearance, or if you want to be able to interchange multiple rear wheels without having to re-adjust the derailer, this could be a problem.
- You can convert an older Freehub body to work with "C" type cassettes by grinding off the outer corners of the splines so that the 11 can fit on far enough to hold the rest of the cassette in place.
Do you want a cassette combination Shimano doesn't make? We carry many individual sprockets for Shimano cassettes, and can provide most sizes. The most economical approach to custom cassettes is to buy a stock cassette that has most of the gears you want, then an additional sprocket or two to substitute for the un-wanted sizes.Although the Hyperglide ramps don't necessarily line up with non-standard sprockets, as a practical matter they tend to work just fine, even if they make a little click when you shift.
Note, in most cases, the smallest sprocket must have a built-in spacer, so, for instance, if you are converting 12-27 into a 13-32, you'll need to buy a new 13, even though the 12-27 comes with a 13.
The differences in thickness between 7-, 8- & 9-speed sprockets that don't have built-in spacers are so small that substituting 2 or 3 in a cassette won't have any affect on the indexing. Similarly, 8-speed top-position cogs work OK with 9-speed cassettes, even though the spacing is different, because the indexing for the smallest sprocket is regulated by the high-gear limit stop of the derailer, not by indexing of the shifter as with the other gears.
Individual Hyperglide Cassette Sprockets
Flat sprockets $9.95 each.
Sprockets with built-in spacer (generally the smallest sizes, for top-gear use). $19.95 each.
For single speed applications, we also carry the BMX Freehub sprockets, which fit all Shimano Freehubs. See our Singlespeed Page.
We carry replacement Freehub ® bodies for Shimano cassette hubs. Most models are interchangeable, permitting you to upgrade older hubs to work with newer systems that feature more sprockets. In some cases you may also need to replace the right side bearing cone. Details of this procedure are explained in my article on Shimano Cassette Hubs.
Notes:
8-/9-speed bodies All work with 8-, 9- or 10-speed cassettes. Part# Model Speeds* Price 11 Tooth
Compatible?CS021 Deore XT M750 9 45.95 Yes CS017 Deore LX M570 9 38.95 Yes CS019 Ultegra 6500 9 52.95 Yes CS016 105 5500 9 41.95 Yes CS020 Dura-Ace 7403 8 SORRY - ALL GONE!
Discontinued by ShimanoNo Only fits pre-1997 Dura-Ace Hubs
Requires Special Tool TL-SH407-speed bodies Part# Model Speeds* Price 11 Tooth
Compatible?CS015 STX-RC 7 22.95 Yes For fixed-gear conversion, we also carry the Surly Fixxer Cassette Hub Converter
- *8- and 9-speed cassettes/bodies are interchangeable. The designation of "8-speed" or "9-speeed" in the table above refers to the group that nominally goes with that model.
- Most of these bodies can be mixed and matched with different hub models, but you may run into problems with compatibility between the right hand cone and the dustcap in the Freehub body.
- "Silent Clutch" and pre '97 Dura-Ace Freehubs only take bodies specifically designed for them.
| Part Number | Series | Price | Sprockets | Weight | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CS850 | Record Exa-Drive | $79.95 | 12 | 13 | 14 | 15 | 17 | 19 | 21 | 23 | ||
| CS849 | Record Exa-Drive | $79.95 | 13 | 14 | 15 | 16 | 17 | 19 | 21 | 23 | ||
| CS851 | Record Exa-Drive | $83.95 | 13 | 14 | 15 | 17 | 19 | 21 | 23 | 26 | ||
| Part Number | Series | Price | Sprockets | Weight | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CS930 | Veloce | $69.95 | 12 | 13 | 14 | 15 | 17 | 18 | 19 | 21 | 23 | 225 grams |
| CS932 | Veloce | $69.95 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 21 | 23 | |
| CS933 | Veloce | $69.95
| 13 | 14 | 15 | 16 | 17 | 19 | 21 | 23 | 26 | |
It is generally good practice to replace your chain when you install a new cassette. We particularly recommend SRAM (Formerly Sachs (Formerly Sedis)) chains. Click here for details.
