Headlights Taillights Generators/Dynamos
BatteryGeneratorMounts BatteryGenerator Tire DrivenHub/Wheel

Headlamps for use with Hub Generators

(These units feature built-in on/off switches)

Select from the brands below:
Supernova E3 lumotec Schmidt E6

Edelux

Threaded BaseBulbsThreaded Base Mounting
Hardware


NEW! Luxos IQ2 "U"

Lumotec IQ CYO RT

LED bicycle generator headlight with USB charge port

New for 2013, the Luxos headlights have a new optical system, IQ2, which provides an even wider beam than the IQ system, and it's brighter too, at 70 or 90 lux. Luxos lights also have B+M's "Licht 24" system of daytime running lights.

The Luxos U is the "deluxe" version. It has innovative new technology that senses rider speed and adjusts light output accordingly, always providing an optimal beam pattern for a given speed. No other light available that is this "intelligent".

The Luxos U incorporates a handlebar mounted switch incorporating a USB outlet for charging USB devices. It also has a cache battery for those devices that might switch off if the dynamo's voltage drops, like when standing at a stop light.

Luxos U Features:

  • 70 or 90 Lux (brightness of the beam at a standard distance)
  • Handlebar mounted switch with USB charge port
  • Licht 24 - Daytime Running Lights
  • Automatic Sensor Switching
  • Standlight
  • Cable Conduit for mount
  • Torx T20 fixing bolt for mount (includes T20 wrench)

Wiring for the headlight to the hub is included.

LT1340 Luxos IQ2 U buy button


divider

NEW! Luxos IQ2 "B"

Lumotec IQ CYO RT

LED bicycle generator headlight

New for 2013, the Luxos headlights have a new optical system, IQ2, which provides an even wider beam than the IQ system, and it's brighter too, at 70 lux. The Luxos B is the "economy" version.

It does not include the USB charge port.

Luxos B Features:

  • 70 Lux (brightness of the beam at a standard distance)
  • Licht 24 - Daytime Running Lights
  • Automatic Sensor Switching
  • Standlight
  • Cable Conduit for mount
  • Torx T20 fixing bolt for mount (includes T20 wrench)

Wiring for the headlight to the hub is included.

LT1339 Luxos IQ2 B buy button


divider

Lumotec Lyt Series

Lumotec Lyt

LED bicycle generator headlight

New for the 2010/11 season. The Lumotec Lyt is the most affordable LED generator headlight yet!


  • 25 lux output
  • Includes fork crown mount bracket.
  • Light comes on automatically with Senso version.
  • LT1352 Lyt N Plus w/standlight $48.00 buy button
  • LT1354 Lyt N Plus Senso & standlight $52.00 buy button

divider

NEW! Lumotec Eyc LED Headlight  buy button Click for current price and options


Lumotec Eyc

LED bicycle generator headlight


The impressive new Eyc (rhymes with "bike", of course) headlights from Busch+Müller are super compact, light, and affordable. They use the new Lumotec "IQ2" reflector technology to throw a beam that is similar to the original Schmidt eDelux light (which was state of the art for lighting just a year or so ago) at less than half the price.

The asymmetrical beam puts the light on the road where it is needed, and not in the eyes on oncoming riders, pedestrians, or motorists.

The Eyc is plenty bright for spirited riding on dark roads.

Two models are available:

- The Eyc N Plus has a simple on/off switch and a stand light that shines when you stop (like at a stop light). It glows for several minutes and is a significant safety feature.

- The Eyc T Senso Plus is the more expensive model which has an on/off switch with an incorporated light level sensor and daytime running lights. When it is "on" in bright light, LED's glow to make you more visible (think "be seen" lights). When the light level is low, the main LED automatically comes on for greater illumination for navigating ("to see" lighting).

divider


NEW! Lumotec IQ CYO Premium T Senso Plus


Lumotec IQ CYO Premium

LED bicycle generator headlight

New for 2013, Busch + Muller has a new CYO Premium series with a brighter and broader beam than the previous models. In addition to upgraded optics, the new light has an improved 2-positon Off/Senso switch. When off, it's off. In Senso mode during daylight, the LED running lights are on. In Senso mode at night, the daytime LED's dim and the main light illuminates the road. Near field illumination is much improved over the previous model as well.

  • 80 lux output
  • Includes fork crown mount bracket and wire cover
  • Lens has built-in reflector

LT1342 IQ CYO Premium T Senso Plus  $110.00  buy button
With black housing.

vertical space
vertical space

divider

LT132B Lumotec IQ Fly N-Plus W/Standlight

Lumotec IQ Fly N-Plus W/Standlight
Model 174QNDi-04

LED bicycle generator headlight

The Lumotec IQ Fly, new for 2008, has a new optical system with a more efficient and brighter LED. All of the light from the LED is aimed backwards at the reflector, and then forwards to the road surface. This provides complete control over the focusing of all the light coming from the LED. The beam is sharply focused, with a sharp horizontal top edge, sides and bottom to the beam, brightest at the top, getting progressively dimmer towards the bottom, like the finest European automotive headlights. With all of the light being focused, there is less spill light outside of the focused patch than with most other headlights. So most of the energy produced by the dynamo, and by your pedaling, goes into making light that illuminates the road.

The result is an extraordinarily bright and wide patch of light ahead of you on the road. While many other dynamo headlights concentrate the beam into a narrow patch, so as to give you the brightest possible patch of light, the new IQ system uses such a bright LED that the light can be spread over a large surface area, and remain very bright. It also means that outside of that bright focused patch, there's less light than with the typical headlight.

Do not combine the IQ Fly with a secondary headlight. The IQ Fly is not compatible with my Secondary headlights. These LED headlights can be used with or without a wired taillight, but the LED will last longer if you use a wired taillight. The LED will get hotter if there is no taillight attached, and the increased heat will shorten the life of the LED.

  • with integral front reflector
  • No upward dazzling light to the rider
  • No loss of light caused by the integral front reflector
  • Tools are not required for cable connection and bulb changing
  • Integral bi-directional Z-diode prevents bulb failure through over voltage
  • Plug contacts for both current and ground
  • LT132B Lumotec IQ Fly N-Plus W/Standlight $71.95 buy button

LT132C Lumotec IQ Fly RT W/Standlight

Lumotec IQ Fly N-Plus W/Standlight
The Lumotec IQ Fly RT adds daytime running lights to the IQ Fly. Six LEDs are positioned below the main lens, integrated into the reflector. When in "Daytime mode" the daytime running lights are at full intensity and the driving or regular LED is at reduced intensity. 40 lux output. This light is bright enough for most any cyclist.

    LT132C Lumotec IQ Fly RT W/Standlight $89.00 buy button

divider

New! Schmidt Edelux II Headlight   buy button Click for current price and color options


Schmidt Edelux II Headlight

Super bright LED.

Hand made by Wilfried Schmidt, it is compatible with 6 volt dynamos from Shimano, SRAM and the SON by Schmidt.

The new Edelux II "raises the beam" for dynamo headlights. The beam is wider, more even, and no longer is there a dark near field area (directly in front of the bike).

The beam is asymmetric (like an automotive low beam) and concentrates the light on the road where it is needed most. Glare for oncoming riders and drivers is reduced. For added safety, a stand light glows for several minutes when the rider stops.

The Edelux II has a three position switch (on/senso/off). In senso mode it will automatically come on in low light (like a tunnel or deep shadows) for safety. The glass lens has a non-glare coating for maximum efficiency and durability. The housing is completely sealed against moisture.

We stock it with a 140 cm wire and bare wire ends. We include loose 4.8mm spade connectors (for Schmidt hubs) at no charge or install them at a specified length for $8 (make a note in the comment field at checkout for this service).

Features include:

  • 140cm wire with loose spade connectors included. We can cut cable to length and install connectors for a $8 additional charge if you prefer (see note above). Make note that this may delay shipment by 24hrs, but generally will not.
  • 80 lux output - SUPER BRIGHT!
  • Standlight
  • On/Off and Senso mode (3-position switch)
  • Aluminium casing and copper heat sink for dissipation of head from the LED
  • Can be used with, or without, a tail light.
  • Available in Black, Silver or polished aluminium
  • Weight: 85g.

  • divider
