Single-Chainring Cranks and Cranksets
from Harris Cyclery

Biopace	110/74 mm "Touring" Triple	110 mm "Compact" Double	130 mm BCD Single/Fixed Gear	130 mm BCD "Road" Double
130/74 BCD "Road" Triple	T.A. Cyclotouriste	Tandem	Bottom Brackets	Chainrings

If you don't see what you're looking for here, try our Quality Bicycle Products Special Order Catalogue



165 mm is Good!

We generally recommend 165 mm length cranks for road fixed-gear use. This shorter length makes it easier to spin faster cadences, and also reduces the risk of striking a pedal while cornering (with a fixed gear, where you have to pedal through the corners, this can be an issue.)



Sugino RD Crank Sets $110.95

Beautiful Sugino Forged cranks with single 48 tooth chainring for singlespeed/fixed-gear use.

• Various lengths available.
• Popular 130 (road standard) bolt circle.
• 575 grams.
• 103 Bottom bracket gives 42 mm chainline, matches most track hubs.

Crank Length	Part #	Order
165 mm	CK1016
170 mm	CK1017
172.5 mm	CK1018
175 mm	CK1019

Limited Supply!  Sugino RD 165mm with 48t Steel 1/8" Chainring
CK1014   $88.95

• We picked up a few of these before the price went up!
• 1/8" chainring requires 1/2x1/8" chain.



Matching Sugino 103 mm Bottom Bracket BB105 $38.95

Very nice quality sealed cartridge bottom bracket, similar to the Shimano UN73.

Aside from Phil Wood , this is the only cartridge BB we know of in the 103 mm length. English threading only.

New!  Origin8 Singlespeed/Fixed Gear Crank Set  CK1144  $59.95

Alloy cranks with single 46 tooth chainring for singlespeed/fixed-gear use.

• Not as nicely finished as the Sugino RD, but more affordable.
• Popular 130 (road standard) bolt circle.
• 3/32"" Alloy ring with champagne finish.
• 165mm arm length.
• 103 Bottom bracket gives 42 mm chainline, matches most track hubs.

New!  Action Track Style Crank Set  CK11522  $58.95

Alloy cranks with single 48 tooth chainring for Singlespeed/fixed-gear use.

• Basic quality. A less expensive alternative to the Sugino RD
• Popular 130 (road standard) bolt circle.
• 1/8" Alloy ring. Requires 1/8" chain.
• 170mm arm length. Left arm included.
• 107mm bottom bracket gives 43-44mm chainline.

Bulletproof Silver 110 BCD Cranks only $36.95

Bulletproof BMX cranks can be used as a single or double chainring setup.

These use the highly versatile 110 mm bolt circle, and fit standard tapered-square bottom bracket axles.

Chainline w/107 mm bottom bracket:

• 43.4 mm as double (middle of spider)
• 47.1 mm outer ring
• 39.7 mm inner ring
• 158 mm tread ("Q factor")

530 grams/pair (165 mm)

Arms only, no bolts nor chainrings included.

Lengths available (not all in stock): 140 mm, 150 mm, 155 mm, 160 mm, 165 mm, 170 mm

Bulletproof Black 110 BCD Cranks only $36.95

As above, but black finish. Only the following lengths are available in black:

• CK237, 165 mm
• CK237, 165 mm

130 mm BCD Cranks for fixed-gear/singlespeed applications

For road applications with fixed gears, you can buy a genuine track crankset, but we normally recommend modifying a "road" double instead.

"Road" cranks are typically considerably less expensive, and use the 130 mm bolt circle, for a much better choice of chainrings at reasonable prices.

Any of the "road" double cranks listed below can be converted to single. All you need is a set of "single" chainring stack bolts.

130 mm BCD "Road" Double Cranks for Fixed/Singlespeed use

You really don't need a fixed-gear specific crankset for your fixed-gear or singlespeed bike. You can use a typical "road double" crankset with the outer chainring removed. You will need a set of short "stack bolts" because the normal double stack bolts will be too long once you remove the outer chainring.

Typical "road" double cranksets put the chainline of the inner (smaller) ring at about 41 mm, which works pretty well with a typical track hub.

See my Chainline Article for details on this.

In addition to the models listed on our main "road double" page, we always keep an eye out for good closeout deals on suitable cranks in 165 mm or shorter lengths:

Special Purchase! Sun Tour Cyclone 7000 Cranksets $79.95 160 mm only

Don't need no steenking pins and ramps? These are gorgeous cranks, with 42/52 chainrings. These N.O.S. cranksets were probably made in the early 1990s

These use the traditional tapered-square bottom bracket.

These use 130 mm BCD chainrings, same as the other "road" cranks listed here.

690 grams including the metal threaded dustcaps.

BB Spindle Length	Chainline between rings	Tread ("Q" Factor)	Clearance Arm from frame midline
110 mm	43.1	146.2	30.1
113 mm	44.6	149	31.6
